Leírás
|
Parameter |
Value |
Unit |
|
|---|---|---|---|
|
Speed |
silent / max |
||
|
Maximum air capacity |
72 / 106 42,408 / 62,434 20,016 / 29,468 0,02002 / 0,02947 1202,4 / 1770,2 |
m³/h CFM l/s m³/s l/m |
|
|
Sound pressure level at 3 m |
22 / 31 |
[dBA] |
|
|
Air flow factory settings |
72 / 82 42,408 / 48,298 20,016 / 22,796 0,02002 / 0,0228 1202,4 / 1369,4 |
m³/h CFM l/s m³/s l/m |
|
|
Regulation range |
33...72 / 72...106 19,437 / 42,408 9,174 / 20,016 0,00917 / 0,02002 551,1 / 1202,4 |
m³/h CFM l/s m³/s l/m |
|
|
Sizes |
ØD |
B |
H |
L |
L1 |
|---|---|---|---|---|---|
|
mm |
100/125 |
152 |
206 |
57 |
29 |
