| Parameter | VENTS 125 X | VENTS 125 XT | VENTS 125 XTH | VENTS 125 XV | VENTS 125 XVT | VENTS 125 X L | VENTS 125 XT L | Measurement unit |
|---|---|---|---|---|---|---|---|---|
| Voltage | 220-240 | V | ||||||
| Frequency | 50/60 | Hz | ||||||
| Power consumption | 16 | W | ||||||
| Air capacity | 164 | m³/h | ||||||
| Current | 0.1 | A | ||||||
| RPM | 2400 | min-1 | ||||||
| Sound pressure level at 3 m | 34 | dBА | ||||||
| Weight | 0.75 | kg | ||||||
| Spigot size | 125 | mm | ||||||
| Engine Type | 220-240V / 50-60Hz | - | ||||||
| Duct diameter | 125 | mm | ||||||
| Design | axial | - | ||||||
| IP Code | IP 24 | - | ||||||
| Type | exhaust | - | ||||||
| Mounting | wall mounting, ceiling mounting | - | ||||||
| Parameter | Value | Measurement unit |
|---|---|---|
| Ø D | 125 | mm |
| B | 177 | mm |
| H | 140 | mm |
| L | 143 | mm |
| L1 | 42 | mm |
