Leírás
| Parameter | TwinFresh Comfo RA1-50 V.3 1 Speed |
TwinFresh Comfo RA1-50 V.3 2 Speed |
TwinFresh Comfo RA1-50 V.3 3 Speed |
Measurement unit |
|---|---|---|---|---|
| Speed | 1 | 2 | 3 | - |
| Voltage | 100-240 | V | ||
| Frequency | 50/60 | Hz | ||
| Power | 4.5 | 5 | 7 | W |
| Current | 0.024 | 0.026 | 0.039 | A |
| SFP | 1.62 | 1.03 | 1.01 | W/l/s |
| Air flow in ventilation mode | 20 | 35 | 50 | m³/h |
| Air flow in ventilation mode | 6 | 10 | 14 | l/s |
| Air flow in energy recovery mode | 10 | 18 | 25 | m³/h |
| Air flow in energy recovery mode | 3 | 5 | 7 | l/s |
| SEC Class | A | - | ||
| Shutters | automatic | - | ||
| Filter | G3 (G4, F7 optional) | - | ||
| Transported air temperature | -20*...+40 | °С | ||
| Sound pressure level at 1 m distance | 22 | 29 | 32 | dBА |
| Sound pressure level at 3 m distance | 13 | 20 | 23 | dBА |
| Outdoor sound pressure attenuation according to DIN EN 20140 | 40 | dBА | ||
| Heat recovery efficiency according to DIBt LÜ-A 20 | ≤ 88 | % | ||
| IP Code | IP 24 | - | ||
| Functions | Filter replacement indication, Timer, Humidity sensor | - | ||
| Remote control panel | - | - | ||
| Duct | 150 | - | ||
| * | -30 °C when the EH-13 hood is applied | - | ||
